Selasa, 02 Juli 2013

MATERI STRUKTUR DATA (Code Lecture)


Topic
  1. Primitive & Abstract Data Types
  2. Lists, Stacks, and Queues
  3. String & File
  4. Trees
  5. Balance Tree
  6. Hashing
  7. Heap
  8. Sorting
  9. Graph
  10. Algoritma & Data Structure Analysis

Literature:
  1. Data Structures and Algorithm Analysis in Java, Mark A l l e n Weiss, Florida International University 2012
  2. Data Structures and Algorithms in Java Fifth Edition International Student Version , Michael T. Goodrich, Department of Computer Science University of California, Irvine
Primitive & Abstract Data Types
Generally data types of all common language divide by 2 types, they are:
  1. Primitive
  2. Abstract (Object)
Primitive data type
Primitive data type is type of data which have static size of memory. Common this data types include:
  1. Integer : byte (8 byte), short (16 b), int (32 b), long (64 b)
  2. Floating point: float (32 byte), double(64 b), decimal(128 b), bigDecimal(256 b)
  3. Booleans: (1 bit)
  4. Characters: (1 byte)
  5. String: (n collection of character-size byte )
Primitive data type
Integer & double Data types, example:
30 byte of double used:1.073741824E9
30 byte of integer used:1073741824
32 byte of double used:4.294967296E9
32 byte of integer used:2147483647
64 byte of double used:1.8446744073709552E19
64 byte of integer used:2147483647
Proof: Maximum value of integer = 2^31 – 1
= 2147483647

Primitive data type
Integers & float Data types, example:
public static void main(String[] args) {
        // TODO code application logic here
        double d = Math.pow(2, 30);
        int i = (int)d;
 System.out.println("30 byte of integer used:"+i);
        System.out.println("30 byte of integer used:"+i);
        d = Math.pow(2, 32);
        i = (int)d;
        System.out.println("32 byte of integer used:"+i);
        d = Math.pow(2, 64);
        i = (int)d;
        System.out.println("64 byte of integer used:"+i);
    }

Primitive data type
Char & String Data Type, example:
   char ch_a = 'A';
        char ch_b = 'B';
        System.out.println("Char: A("+ch_a+") Char B:"+ch_b);
        String s = Character.toString(ch_a)+Character.toString(ch_b);
        System.out.println("String S:"+s);
        ch_a = s.charAt(0);
        System.out.println("Char A:"+ch_a);
   ch_b = s.charAt(1);
        System.out.println("Char B:"+ch_b);
Proof : String is collection of characters

Dynamic Memory Create of Primitive Data Type to Object
Base Type
Class Name
Creation
Access
Byte
Byte
n new Byte((byte}34);
n.byteValueOf()
short
Short
n new Short((short}100);
n.shortValueOf()
int
Integer
n = new Integer(1045);
n.intValueOf()
long
Long
n = new Long(10849L);
n.longValueOf()
 float
Float
n = new Float(3.934F);
n.floatValueOf()
double
Double
n new Double{3.934};
n.doubleValueOf()

Java Primitive to Dynamic Object Casting
Usually, primitive data type is statically typing for casting each others, but with using of Object type can to cast dinamically.
Example:
   int i = 100;
        String s = String.valueOf(i);

        System.out.println(s);

Java Primitive to Dynamic Object Casting
Dynamic Object Casting,
Example:
public class TestMemory{
// Object for abstract data type
    public Object read( ) {
        return storedValue;
    }
    public void write( Object x ) {
        storedValue = x;
    }

Java Primitive to Dynamic Object Casting
private Object storedValue;
     public static void main(String[] args) {
        TestMemory t = new TestMemory();
        t.write( 33 );
        String vi = (String) t.read().toString();
        System.out.println( "Contents of String for integer are: " + vi );
        TestMemory m = new TestMemory();
        m.write( "my age: " );
        String vs = (String) m.read();
        System.out.println( "Contents of String are: " + vs + vi );
     }
}

Collection of Object Data Types
Collection is set of object with dynamic type inside.
Type of collection in Java include:
  • Array, static collection of the same primitive data types with index.
  • List, dynamic collection of objects with index
  • Map, dynamic collection of objects with key & value
Collection of Array
public class Array{
    int index = 10;
    int []  arr= new int[index];

    public void setArray(int index, int val){
        for (int i=0;i
arr[i]= val;
            }
}
    public int getArray(int index){
        return arr[index];
    }
}

Collection of Array
public class Matrik {
    int bar = 10;
    int kol = 10;
    double [][] mtr = new double[bar][kol];

    public void setMatrix(int row,int col, double val){
        for (int i=0;i
            for (int j=0;j
                mtr[i][j]= val;
            }
        }
    }
    public double getMatrix(int row, int col){
        return mtr[row][col];
    }
}

Collection of Dynamic Array
public void setValue(int row, int col, double value) {
        if (row >= matrix.length) {
            double[][] tmp = matrix;
            matrix = new double[row + 1][];
            System.arraycopy(tmp, 0, matrix, 0, tmp.length);
            for (int i = row; i < row + 1; i++) {
                matrix[i] = new double[col];
            }
        }

        if (col >= matrix[row].length) {
            double[] tmp = matrix[row];
            matrix[row] = new double[col + 1];
            System.arraycopy(tmp, 0, matrix[row], 0, tmp.length);
        }

        matrix[row][col] = value;
    }

Collection of List Object Data Types
import java.util.ArrayList;
import java.util.List;

public class Student {
    String  name;
    String  faculty;
    int     level;
    static List listOfStudents = new ArrayList();
    public String toString(){
        return this.name+"|"+this.faculty+"|"+this.level;
    }
    Student(String pname, String pfaculty, int plevel){
        this.name=pname;
        this.faculty=pfaculty;
        this.level=plevel;
    }

Collection of List Object Data Types
public static void main(String[] args) {
        Student s = new Student("adi", "technic", 1);
        s.listOfStudents.add(s);
        System.out.println(s.toString());
        s = new Student("wati", "economics", 3);
        s.listOfStudents.add(s);
        System.out.println(s.toString());
        s.listOfStudents.add("gatot");
        s.listOfStudents.add(1000);
        for(int i=0; i
        System.out.println(s.listOfStudents.get(i).toString());
    }
}

Collection of Map Object Data Types
public static void main(String[] args) {
 HashMap mapOfStudents = new HashMap();
        List ls = new ArrayList();
        Student s = new Student("adi", "technic", 1);
        ls.add(s);
        s = new Student("eko", "technic", 3);
        ls.add(s);
        s = new Student("zaid", "technic", 5);
        ls.add(s);
        mapOfStudents.put("mahasiswa teknik", ls);
        List result = mapOfStudents.get("mahasiswa teknik");
        for(int i=0; i
            System.out.println(result.get(i).toString());
        }
}

Exercise Problem...?



Materi  ini di ajarkan di Universitas Trunojoyo Madura (UTM) Jurusan Teknik Informatika. Untuk Lebih Lengkapnya Download saja langsung di bawah ini. Semoga bermanfaat ^_^

Download materi Disini











Kritik dan Saran layangkan ke Facebook dan Email: Hasan.kawaguchi24@gmail.com
